Should the bulk lsoh flexible electric wire made in China caters to your requirement, welcome to get the datasheet with us. As one of the leading manufacturers and suppliers in China, we also offer the customized service.450/750V Copper Conductor LSOH Insulation Flexible Electric Wire
Description:
Conductor: Bare Copper
Insulation: LSOH
Color:Black,White,Red,Yellow,Blue,and etc.,
Voltage Rating:450V/750V
Max Temperature Rating:70℃-150℃
Typical Application:
For Building Wiring, Installation ,Equipment and Instrument
Best Feature LSOH Insulation:
Low smoke zero halogen (LSZH or LSOH) is a type of plastic used in the wire and cable industry for cable jacket. LSOH cable jacket is to produce minimal smoke and no halogen when exposed to fire.
In the past most housing wire as well as network cable are insulated with poly vinyl chloride (PVC), PE, or thermoplastic urethane (TPU). Halogen-containing plastic releases hydrogen chloride, a poisonous gas that forms hydrochloric acid when in a fire, Zero Halogen cables are environment-friendly and do not produce this toxic combination of gas, acid, and smoke when exposed to flame.
Low smoke zero halogen cable is becoming popular, Low Smoke Zero Halogen compound also has the added benefit of complying with the European Union’s Restriction of Hazardous Substances (RoHS) directive and similar North American safety and environmental standards.
450/750V Copper Conductor LSOH Insulation Flexible Electric Wire | ||||
Nom. Cross Section(mm²) | Conductor Structure(mm) | Conductor O.D.(mm) | Thickness of Insulation(mm) | O.D. Of Jacket(mm) |
0.5 | 16/0.25 | 0.92 | 0.7 | 2.32 |
0.75 | 24/0.20 | 1.13 | 0.7 | 2.53 |
1 | 32/0.20 | 1.58 | 0.7 | 2.71 |
1.5 | 30/0.25 | 2.02 | 0.7 | 2.98 |
2.5 | 49/0.25 | 2.59 | 0.8 | 3.62 |
4 | 56/0.30 | 3.60 | 0.8 | 4.19 |
Our 5 Orange LSZH Sta Water Resistant Cable (BTLY) /Electricals /Electronic Wire/ Cable Wires quality control is strict, according to the international production process. Our factory has always emphasized on technological innovation and research development. Whether products are good or bad depends on whether they meet the requirements of customers.
