This product is suitable for indoor, pipeline and general industrial environment and other electronic computers and automatic connection cables for occasions requThe cable conductor tinned wire core insulation, polyethylene, polyethylene, high insulation resistance, voltage resistance, impact of small and medium dielectric constant temperature and variable frequency of loss is small, not only to meet the transmission performance requirements, but also to ensure that the service life of the cable.
AWG Sizes | Conductor | Insulation | Twisted Pair | Overall Shielding | Jacket | ||||
Roots/Diameter(mm) | O.D. | Thickness | O.D(mm) | O.D. | Shielding | Thickness | O.D. | ||
1*2*24AWG | 7/0.20 | 0.60 | 0.4 | 1.40 | 2.80 | Al Foil | Copper wire Braiding | 1.0 | 5.5 |
2*2*24AWG | 7/0.20 | 0.60 | 0.4 | 1.40 | 2.80 | Al Foil | Copper wire Braiding | 1.0 | 8.6 |
3*2*24AWG | 7/0.20 | 0.60 | 0.4 | 1.40 | 2.80 | Al Foil | Copper wire Braiding | 1.0 | 9.0 |
4*2*24AWG | 7/0.20 | 0.60 | 0.4 | 1.40 | 2.80 | Al Foil | Copper wire Braiding | 1.0 | 9.9 |
1*2*22AWG | 7/0.25 | 0.75 | 0.5 | 1.75 | 3.50 | Al Foil | Copper wire Braiding | 1.0 | 6.2 |
2*2*22AWG | 7/0.25 | 0.75 | 0.5 | 1.75 | 3.50 | Al Foil | Copper wire Braiding | 1.0 | 10.0 |
3*2*22AWG | 7/0.25 | 0.75 | 0.5 | 1.75 | 3.50 | Al Foil | Copper wire Braiding | 1.2 | 10.9 |
4*2*22AWG | 7/0.25 | 0.75 | 0.5 | 1.75 | 3.50 | Al Foil | Copper wire Braiding | 1.2 | 12.0 |
1*2*20AWG | 7/0.30 | 0.90 | 0.6 | 2.10 | 4.20 | Al Foil | Copper wire Braiding | 1.0 | 6.9 |
2*2*20AWG | 7/0.30 | 0.90 | 0.6 | 2.10 | 4.20 | Al Foil | Copper wire Braiding | 1.2 | 11.8 |
3*2*20AWG | 7/0.30 | 0.90 | 0.6 | 2.10 | 4.20 | Al Foil | Copper wire Braiding | 1.3 | 12.6 |
4*2*20AWG | 7/0.30 | 0.90 | 0.6 | 2.10 | 4.20 | Al Foil | Copper wire Braiding | 1.3 | 13.9 |
1*2*18AWG | 7/0.40 | 1.20 | 0.75 | 2.10 | 4.20 | Al Foil | Copper wire Braiding | 1.0 | 8.1 |
2*2*18AWG | 7/0.40 | 1.20 | 0.75 | 2.10 | 4.20 | Al Foil | Copper wire Braiding | 1.3 | 14.4 |
3*2*18AWG | 7/0.40 | 1.20 | 0.75 | 2.10 | 4.20 | Al Foil | Copper wire Braiding | 1.3 | 15.2 |
4*2*18AWG | 7/0.40 | 1.20 | 0.75 | 2.10 | 4.20 | Al Foil | Copper wire Braiding | 1.3 | 16.8 |
The cable adopts the structure of the screen or the main screen, which can reduce the mutual crosstalk and external interference between the circuits, and can improve the transmission quality of the cable signals in one frequency. Special occasions can also be used as required to protect the armor layer, to enhance the impact resistance of cables.iring high anti-interference.
