Description:
. Conductor :Bare Copper
. Insulation Material: Foam PE
.1st Shielding: Aluminum Tape
.2nd Shielding: Tinned Copper Braiding
. Impedance:50Ω±2
.Jacket: PE, PVC, LSZH
. Color: Black,White
Typical Application:
1.SYWV50-7 is the same specification as 7D-FB coaxial cable Kansai standard, generally designed for jumper assemblies in wireless communications systems
2.SYWV50-7(7D-FB) has PE jacket, PVC jacket, LSZH jacket Flame-retardant LSZH jacket, Flame-retardant PVC jacket for different environment
3.7D-FB coaxial cable is used in 3G, GSM, and CDMA telecommunication system, digital microwave communication system, and aeronautics and space industry, precise instrument
Best Feature:
SYWV50-7(7D-FB) cable features a foam PE insulation coaxial cable with stable performance low loss, low delay and excellent attenuation constant for telecommunication usage.
Custom service:
We also supply 7D-FB cable assembly with N connector to SMA connector
Standard Packing: 1000m/ wooden drum and pallet
SYWV50-7(7D-FB) foam PE insulated coaxial cable specifications | |
Material of Inner Conductor | BC (Bare Copper) |
Structure of Inner Conductor | 1/2.60mm |
Material of Insulation | FPE(Foam PE) |
Diameter of Insulation | 7.30mm |
1st Shielding | Aluminum Tape |
Material of Braiding(2nd Shielding) | TC (Tinned Copper), |
Structure of Braiding(2nd Shielding) | 112/0.15mm |
Material of Jacket | PVC, PE, LSZH,FR-LSZH |
Diameter of Jacket | 10.20mm |
Working temp | -40℃/80℃ |
Impedance | 50Ω±2 |
Voltage | 2500V |
SWR(0-2500MHz) | ≤1.2 |
Nominal Weight(KGS/KM) | 100 |
Why Choose Us
1. Quick Response -The inquiries will be replied within 24 hours.
2. Professional Quotation- We will quote the price as per customers' detailed specifications & requirements.
3. Stable Quality -The raw material is complied to RoHs. with SGS and REACH test report. The laboratory is equipped with 20GHz Agilent net-work analyzer, the cable is test each step so as to strictly ensure the quality.
4. Fast Delivery -7-15 days after confirmation.
5. Good After-sales Service
FAQ
1.Are you a trading company or manufacturer?
We are manufacturer.
2.Can you put our logo into product surface or poly bag?
It needs to be checked before signing the contract.
3.How can I get prices?
Send us your enquiry by either email or fax, we will offer to you soon. Also, let us know the trade term and payment terms so that we can quote accordingly.
4.If I want to release order, what’s the payment method you accept?
We accept T/T, Paypal, Western union, L/C, Trade Assurance.
5.Can I order some samples before placing batch order and how do you ship them?
It depends on the cable description, order possibility and our stock.
Normally, we can send the samples to you by courier or by air.
