RG22 75ohm Coaxial Cable

RG22 /U coaxial cable Description ： . Standard Mil-c-17 . Conductor:Tinned Copper . Insulation Material: Solid PE . 1 st Shielding:Bare Copper Braiding . 2 nd Shielding:Bare Copper Braiding . Armor: Aluminum Braid . Outer jacket:PVC . Color: Black . Impedance:50Ω±2 Typical Application: RG-22/U...

Should the bulk rg22 75ohm coaxial cable made in China caters to your requirement, welcome to get the datasheet with us. As one of the leading manufacturers and suppliers in China, we also offer the customized service.

RG22 /U coaxial cable Description：

. Standard Mil-c-17

. Conductor:Bare Copper 7*0.32mm

. Insulation Material: Solid PE

. 1^st Shielding:Bare Copper Braiding

. 2^nd Shielding:Bare Copper Braiding

. Armor: Aluminum Braid

. Outer jacket:PVC

. Color: Black

. Impedance:75Ω±3

Typical Application: RG-22/U coax cable is often used for direct burial applications.

data transmission, broadcast, and telecommunications applications. RG-22 cable is easily matched to transmitter video signals and may also be used in a variety of instrumentation and control applications.

Best Feature: high voltage coaxial cable

RG12/U coaxial cable specifications
Material of Inner Conductor	TC(Tinned Copper)
Structure of Inner Conductor	7/0.32mm
Material of Insulation	Solid PE
Diameter of Insulation	7.24mm
Material of Braiding(Double Shielding)	BC(Bare Copper)
Structure of Braiding(Double Shielding)	144+168*0.15mm
Material of Jacket	PVC
Diameter of Jacket	11.80mm
Working temp	-40℃/80℃
Impedance	75Ω±3
Voltage	4000V
Weight	140KG/KM
