75 Ohm Bt 3002 Coaxial Cable (Single)

Basic Info

• Model NO.: BT 3002

• Conductor Material: BC/CCS/CCA/TC/CU/CCAG

• Type: Coaxial Cable

• Conductor Type: Solid

• Certification: CE, ISO, RoHS, UL

• Brand: Elesun

• Dielectric: 2.0mm Solid PE

• Braid 2ND Coverage: 16*6*0.10mm Tc Wires (92%)

• Impedance: 75 Ohm

• Trademark: Elesun

• Specification:  ROHS, REACH,  ISO, SGS,

• HS Code: 85442000

• Application: Coaxial Cable

• Cover Material: PVC

• Material Shape: Round Wire

• Wire Core Material: Bare Copper Wire

• Model: Bt3002

• Center Conductor: 0.31mm Plain Annealed Copper

• Braid 1st Coverage: 16*5*0.10mm Tc Wires (91%)

• Jacket: 3.8mm PVC

• Nominal Capacitance: 67 PF/M

• Transport Package: Coil, Wooden Reel, Plastic Reel, and Paper Reel

• Origin: Jiangsu， China

Product Description

BT 3002 (Single)

PHYSICAL SPECIFICATION


ELECTRICAL SPECIFICATION


Attenuation @ 60°F(20°C)

Packing
1) Packing Lengths:100/roll,200 m/roll, 300m/roll. 305m/roll

2) Inner Packing: Wooden reel, plastic reel, and paper reel

3) Outer Packing: Carton box, pull out box, pallet available

4) Other packing available according to clients' request

About US


We are a cable products manufacturer located in Jiangsu Province, China.

2 hours reach Shanghai port. 150 employees, 10 years international trading experience.

Our product covers:

- Coaxial Cable(SYV/SYWV/D-FB/C-V/RG/Teflon)

- Control Cable(KVV/KVVP)

- Electronic Wire (THNN/THWN/UL1007/1015)

- BV/RV wire (LSOH / XLPE)

- LAN Cable UTP, STP, FTP

(With UL certificate & Rosh)
